Metal Stamping Engineering Services - DFM, PPAP Support and CAD/CAM Design

Design for Manufacturability for Metal Stamped Parts

ATD provides engineering services that help manufacturers move metal stamped components from initial concept to full production with fewer delays, lower risk and greater cost control. Our team supports prototypes, tool and die design, metal stamping, secondary operations, sub-assemblies and finished goods.

By combining advanced CAD/CAM software, practical tooling knowledge and decades of manufacturing experience, ATD identifies production challenges before they create expensive problems. Our engineers apply design for manufacturability principles early in the development cycle to reduce tooling costs, improve part consistency and accelerate the production part approval process.

metal stamping engineers reviewing DFM analysis
CAD design for progressive die stamping tool

PPAP-Compliant Engineering from Prototype to Production

Successful metal stamping programs begin long before production starts. Early engineering involvement gives ATD the opportunity to evaluate part geometry, material selection, tolerances, forming requirements and tooling strategy before major investments are made.

This collaborative approach helps customers avoid unnecessary tooling revisions, reduce material waste and build a more reliable path to production. From the first CAD file review through PPAP submission, our engineering team provides the technical oversight needed to bring durable, repeatable parts to market.

What Is Design for Manufacturability?

Design for manufacturability, or DFM, is an engineering practice that optimizes part design for efficient, cost-effective production. ATD’s engineering team applies DFM principles early in the product development cycle to identify potential stamping challenges, reduce material waste and minimize tooling revisions before steel is ever cut.

A DFM review may uncover issues involving bend radii, material flow, hole placement, tolerance requirements, part orientation or the number of forming operations required. Addressing these concerns during the design stage can reduce tooling complexity, improve press performance and lower scrap rates throughout production.

For procurement engineers and product teams, DFM also creates greater confidence in project timing and cost. Instead of reacting to problems after tooling has been built, ATD helps customers make informed design decisions before those problems affect launch schedules or production budgets.

Explore Related Capabilities

ATD provides more than standalone engineering support. Our one-stop shop model helps customers reduce transportation, limit handling and avoid coordinating multiple secondary suppliers.

Prototyping

ATD produces functional prototypes that allow customers to evaluate form, fit and function before production tooling is completed.

Equipment

Our manufacturing capabilities include advanced CAD/CAM systems, precision machining technology and servo and mechanical presses designed to support repeatable metal stamping production.

Tooling Transfer

ATD helps customers move existing tooling programs with a structured assessment process that evaluates tool condition, production readiness and transfer risk.

CAD/CAM Software: SolidWorks, Siemens NX and Mastercam 2024

Using the latest software enables us to program directly from a native CAD file, saving programming time and eliminating potential translation errors. We use the following cutting-edge software.

  • CNC - Mastercam 2023
  • WEDM - Fanuc Robocut CAM
  • Design - Siemens NX 2023 and Solidworks 2023



employee reviewing design

ATD's CAD Expertise Produces Big Cost Savings for Automotive Manufacturer

Learn how ATD saved an automotive manufacturer hundreds of thousands of dollars by using CAD software to pinpoint a failure and design a new part.

“We were able to tell them that if they went down the path they’ve used for these other tools they’ve built and are running, this part is going to fail. Right up front, in the very early stages of the laying out of this tool, we were able to get that in front of them — before steel was ordered, before die was set, before a lot of costs were accrued.”

Robert Matis, ATD Senior Tooling Engineer and Estimator

Robert Matis
ATD Senior Tooling Engineer and Estimator
